◎ 4.3”WVGA color capacitive touchscreen

 ◎ Loudspeakerµphone Intercom function

 ◎ Audio & videoplayer

 ◎ Touchless fingerprintsensor
       Handpresence detection QR code scanning capability

 ◎ Contactlessreaderoptions：Prox,iClass, MIFARE/DESFire

 ◎ Tamper seitches

 ◎  Internal storage capacity：16GB Flash, 2GB RAM
       -20,000 user records (2*4 fingers each) for 1:N identification,
       extendable to 40,000 with licenses.
       -250,000 IDs in authorized user list - 1 Million transaction logs

 ◎ Network/Communication：
       －  Ethernet, RS485, RS422, USB

 ◎ Inputs/outputs：Wiegand In & Out (customizable up to 512 bits),
　　　　　　　　　　　　　Door Relay, 3 GPI (including Door monitoring), 3 GPO

 ◎ Power supply：12 to 24 V DC (2.5A min @12V) Power over Ethernet with PoE+ switches

 ◎ Operating conditions：－Temperature: -10°C to 55°C (14°F to 131°F)
　　　　　　　　　　　　　　　　　－Humidity: 10% to 95% (non condensing)

 ◎ Ingress protection：IP65

 ◎ Host Interface：250*152*216 mm

 ◎ Weight：2.2 kg

 ◎ EMC/Safety standards：CE, CB, FCC

 ◎ RoHS, REACh and WEEE compliant
